페인트, 잉크, 접착제, 전자재료 분야등 다양한 사업영역에서 필수적인 재료로 사용되는 PVB 수지를
공급하고 있으며, PVB 수지의 전문적인 지식을 바탕으로 체계적인 기술지원을 제공하고 있습니다.
Main Grades and Specifications
| Grade | Butyral mol% |
Hydroxyl mol% |
Acetyl mol% |
Viscosity cps |
Free Acid wt% |
Volatile wt% |
|---|---|---|---|---|---|---|
| Grades for Wash Primer, Paint, Ceramic Binder, Coating, Adhesive | ||||||
| B18HX | 65.2~73.5 | 26.2~32.7 | < 2.2 | 60~1001 | < 0.05 | < 3 |
| B17HX | 65.2~73.5 | 26.2~32.7 | < 2.2 | 60~1001 | < 0.05 | < 3 |
| B08HX | 68.4~73.8 | 26.2~30.1 | < 1.5 | 110~1802 | < 0.05 | < 3 |
| B06HX | 67.6~73.8 | 26.2~30.2 | < 2.2 | 70~1002 | < 0.05 | < 3 |
| B05HX | 67.6~73.8 | 26.2~30.2 | < 2.2 | 40~702 | < 0.05 | < 3 |
| B08SY | 76.8~83.4 | 16.6~20.9 | < 2.3 | 100~1602 | < 0.05 | < 3 |
| B06SY | 76.8~83.4 | 16.6~20.9 | < 2.3 | 30~802 | < 0.05 | < 3 |
| B05SY | 76.8~83.4 | 16.6~20.9 | < 2.3 | 10~302 | < 0.05 | < 3 |
| Grades for Copper Foil and Printed Circuit Board | ||||||
| B17TX | ------- | 17.0~20.9 | < 1.3 | 80~1203 | < 0.05 | < 3 |
| B12TX | ------- | 19.7~23.6 | < 2.0 | 150~2203 | < 0.05 | < 3 |
| B11TX | ------- | 19.7~23.6 | < 2.0 | 100~1503 | < 0.05 | < 3 |
| B10TX | ------- | 19.7~23.6 | < 2.0 | 60~1003 | < 0.05 | < 3 |
| Grades for Copper Foil and Printed Circuit Board | ||||||
| B04HX | 67.6~73.8 | 26.2~30.2 | < 2.2 | 30~402 | < 0.05 | < 3 |
| B03HX | 67.6~73.8 | 26.2~30.2 | < 2.2 | 10~302 | < 0.05 | < 3 |
| B02HX | 67.6~73.8 | 26.2~30.2 | < 2.2 | 16~204 | < 0.05 | < 3 |
| B03TX | ------- | 20.9~23.6 | < 2.0 | 25~404 | < 0.05 | < 3 |
| Grade | Degree of Polymerization | Molecular Weight(Mw) | Tg (°C) | Tm(°C) |
|---|---|---|---|---|
| B-18FG | 1700- 1800 | 110,000-125,000 | 74 | 160-210 |
| B-18FS | 1700-1800 | 110,000-125,000 | 74 | 160-210 |
| B-20HX | 1900-2000 | 122,500-131,000 | 74 | 160-210 |
| B-18HX | 1700-1800 | 110,000-125,000 | 74 | 160-210 |
| B-17HX | 1700-1800 | 110,000-125,000 | 74 | 160-210 |
| B-08HX | 800-900 | 52,000-62,000 | 71 | 135-185 |
| B-06HX | 600-700 | 40,000-50,000 | 68 | 135-175 |
| B-05HX | 500-600 | 32,000-42,000 | 62 | 135-170 |
| B-04HX | 400-500 | 25,000-35,000 | 62 | 135-170 |
| B-03HX | 300-400 | 20,000-30,000 | 62 | 135-170 |
| B-02HX | 200-300 | 16,000-20,000 | 60 | 125-170 |
| B-08SY | 800-900 | 55,000-65,000 | 64 | 135-180 |
| B-06SY | 500-600 | 32,000-45,000 | 63 | 130-180 |
| B-05SY | 300-400 | 20,000-32,000 | 62 | 130-180 |
| B-03TX | 300-400 | 18,000-28,000 | 80 | 135-175 |
