PTFE 불소수지

PTFE는 Polytetrafluoroethylene의 약자이며 대표적인 불소수지로 폴리에틸렌의 분자구조에서 수소원자를 불소원자로 치환시킨 고분자물질로서 내마모성, 내수성, 내유성, 내화학성, 내약품성, 저마찰계수, 비점착성, 전기절연성, 불연성, 내후성등을 보유하고 무독성 물질로 알려져 있습니다. 특히 -250℃ ~ 300℃ 정도의 광범위한 사용온도에서 안정성을 유지하여 특성이 변화하지 않으며 압출, 사출, 도료, 접착, 잉크, 코팅, 페인트, 파이프, 배관, 전자재료 및 다양한 산업에서 핵심 원료 및 첨가제로 사용되고 있습니다.


  FEATURES


  • Excellent chemical inertness
  • Outstanding resistance to chemical corrosion : strong acid, alkali, oxidant, etc.
  • Broad range of temperature from -200℃~250℃
  • Superior electric insulation, which is not affected by temperature and frequency.
  • Non-stick to all other materials.
  • No-Absorption of Moisture
  • Flame retardation.


  APPLICATIONS


  • Non Stick Coating, Spray Coating, Roller Coating, Silk-Screen Coating
  • Additives for Paint, Ink, Printing
  • Additives for Rubber, Silicone, Urethan, EPDM, NBR, TPU, Elastomer
  • Additives for Off Set Ink, UV Ink, Can Ink, Photo Ink, Metal Ink, Resist Ink
  • Additives for POM, PPS, LCP, PEEK, PC, PA, PES, PI, PEI, PAI, PSU, PEN, PBT, ABS, PP, PE, Epoxy, Phenol Resins


pvb수지

  PACKING & HANDLING


  • Stored under frost proof environment under optimum 3-30℃ temperature
  • Should not store under 0℃ or over 40℃ temperature
  • Homogenized by gentle rolling or stirring when storing or using
  • Adjust viscosity by adding distilled water or anion surfactant
  • PH could be adjust by ammonium hydroxide
  • Package in 25L PE drum with 25kg(55lb) and 1000L IBC drum with 1250kg(2750lb)

PRODUCT & SPECIFICATIONS

Product Application Type Size(um) Tensile(Mpa) Elongation(%) Melting(℃)
M40 Molding Powder 20~40 35 375 327 ± 10
M120 Molding Powder 120~180 35 375 327 ± 10
G401 Gasket/Seal/Rod Powder 490 35 330 327 ± 10


Product Application Type Size(um) EXT(Mpa) T.I Melting(℃)
F100 Sealing Tape Powder 500 8 < 50 341
F500 Tube/Cable/Wrap Powder 480 23 < 7 341
F1000 Wire/Tube/Cable Powder 480 53 < 50 341


Product Application Type S.C(% PTFE) Size(um) PH 23(℃) Visco (mPa.s)
D60 Non Stick Coating Dispersion 60 0.25 9 20


Product Application Type Gravity(g/L) Size(um) M.P(℃) S.A(cm2//g)
MV1 Lubricant Micropowder 350 1~3 >326 17
MV3C Paint/Coating Micropowder 350 3~5 >326 17
MV3I Ink/Print Micropowder 350 3~5 >250 17
MV3E Rubber/EPDM/SBR Micropowder 350 5 >326 17
MV5P PA/POM/PC Micropowder 350 9~12 >326 17


APPLICATIONS

MㆍG Series
  • Molding
  • Gasket
  • Seal
  • Rod
FㆍD Series
  • Sealing material tape
  • Tube/Cable/Wrap
  • Wire/Tube/Cable
  • Non-stick coating
MV Series
  • Lubricant
  • Paint/Coating
  • Ink/Print
  • Rubber/EPDM/SBR
  • PA/POM/PC
